PC-I | DA4 002566 | NOS boxed

PC-I

Serial: DA4 002566

  • CPU: Siemens 8088 @ 4.77mhz
  • Motherboard: 380078 rev 3
  • BIOS: rev 1.1
  • RAM: 512k
  • ROM: 256k
    • Pheonix 128k BIOS
    • 128k character ROM
  • Video: Hercules
    • Text: 80 x 25 x 16
    • CGA: 320 x 200 x 4, 640 x 200 x 2
    • CGA: 320 x 200 x 16,640 x 200 x 4
    • Hercules: 720 x 348 x 2
  • Sound: 1 channel mono (no buzzer)
  • Additional Hardware: 5.25″ Floppy Disk Drive 360K Chinon FZ-502
  • Ports: 6551, MC6845, MOS 5720
    • 25 pin female parallel
    • 25 pin male serial (9600/115200 baud)
    • 60 pin edge connector (Expansion)
    • RGBI Video port
    • RF Video port
    • Power plug and switches
    • 4 dip switches for Video
    • Proprietary DDFD (5.25″ or 3.5″) port
  • Keyboard: Full-sized 84 key QWERTZ
    • 10 programmable function keys
    • 16 key numeric key
  • work performed:
    • defective PSU recapped with Rubycon brand 105° type, working again
  • general notes:
    • factory sealed new-old stock with original box and warranty card (seal survived opening the case)
