AMIGA 1200 | 530311

AMIGA 1200

Serial: 530311

  • CPU Motorola 68EC020 / 14 MHz,
  • RAM: 2 MB CHIP RAM on-board
  • RAM expansion: without accelerator card up to 8 MB, up to 256 MB with accelerator card
  • ROM version: 3.00 | 39.106
  • AGA graphics system, color palette of 16.8 million colors (24 bits), up to 64k colors (HAM8) displayable
  • AGA resolutions:
    320 x 200 pixels non-interlaced
    1280 x 512 pixels interlaced
    640 x 480 pixels non-interlaced
    640 x 400 pixels non-interlaced
    800 x 600 pixels interlaced
    and more
  • Video and genlock compatible
  • Four channels of 8 bit PCM DMA sound
  • Country-specific keyboard, 96 keys
  • High resolution mouse 400 dpi, 2 buttons
  • 16-bit IDE interface for internal 2.5″ hard disks
  • Internal floppy disk drive 3.5″ DD, 880 KB AMIGA, 720 KB MS-DOS
  • I/O:
    • 1x serial RS-232c (modem)
    • 1x parallel (printer)
    • 1x external floppy disk drive connector for up to three additional drives
    • 2x mouse/joystick
    • 1x video RGB (monitor)
    • 1x video composite (TV, VCR)
    • 1x RF (TV antenna)
    • 1x stereo audio (L/R)
    • 1x PCMCIA V2.0 16-Bit slot for RAM cards (max. 4 MB, 16 Bit), Ethernet cards, or other PCMCIA expansion cards
    • 1x internal CPU slot for memory expansions or accelerator boards
    • external switching power supply, 25 W
  • Dimensions: ca. 490 mm x 250 mm x 70 mm (W x D x H)
  • work performed:
    • totally dismantled and cleaned
    • completely recapped with ceramic capacitors
    • missing upper shielding and case screws replaced
